Tabung Stainless Steel Dipoles Dingin / Panas Dipoles ASTM 410 430 304L 316L Standar
Properti Dasar
Tempat Asal:
Cina
Nama Merek:
New Era
Sertifikasi:
ISO9001,TS16949
Nomor Model:
ASTM A410 430
Properti Perdagangan
Jumlah Pesanan Minimum:
1 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
T/T, L/C
Kemampuan Pasokan:
1000 ton/bulan
Ringkasan Produk
ASTM 410 430 304L 316L Pipa Stainless Steel Seamless, pipa stainless steel yang dipoles Deskripsi produk: Bahan 304:0cr18ni9, 0cr17ni8 201:1cr17mn6ni5n,1cr13mn9ni1n 316:0cr17ni12 atau sebagai permintaan pelanggan Ukuran (pipa bulat) 9.5, 12.7, 15.9, 17, 18, 19.1, 20, 21, 22.2, 23, 25.4, 28, 318, 35, ...
Detail Produk
Menyoroti:
Tabung Stainless Steel Mulus yang Dipoles
,Tabung Stainless Steel ASTM Dipoles
,Tabung Stainless Steel Mulus 304L
Material:
904L TP304, TP304L, TP316, TP316L, TP321, TP247H, dll.
Delivery Condition:
Anil dan Acar, Anil Cerah, Dipoles Secara Mekanis
Process Method:
Mulus atau dilas
Application:
untuk industri otomotif
Technique:
Cold Rolled Hot Rolled, Cold Drawn, Seamless / Welded
Products:
Tabung baja tahan karat 904L
Deskripsi Produk
ASTM 410 430 304L 316L Pipa Stainless Steel Seamless, pipa stainless steel yang dipoles
Deskripsi produk:
| Bahan |
304:0cr18ni9, 0cr17ni8 201:1cr17mn6ni5n,1cr13mn9ni1n 316:0cr17ni12 atau sebagai permintaan pelanggan |
| Ukuran (pipa bulat) |
9.5, 12.7, 15.9, 17, 18, 19.1, 20, 21, 22.2, 23, 25.4, 28, 318, 35, 60, 63.5, 73, 76.2, 88.9, 101.6, 114,3, 127, 133, 159, 168, 219 mm atau disesuaikan |
| Ukuran (pipa persegi) |
10×10,12×12,18×18,23×23,38×38,50×50,70×70,100×100,20×10,23×10,24×12,25×13,36×23, 40×20,50×20,60×15,75×45,80×60,95×45,100×60,150×100 mm atau disesuaikan |
| Ukuran (pipa oval) | 30 × 15,80 × 40 mm atau disesuaikan |
| Ketebalan | 0,24-3 mm |
| Panjangnya | 6m atau sesuai permintaan pelanggan |
| Diameter luar | 6.35-219mm |
| Toleransi | Diameter luar: ± 0.2mm |
| Ketebalan: ± 0,02mm | |
| Panjang: ± 0,5mm | |
| Metode proses | Kode ditarik, dianil dengan perlindungan nitrogen, ultrasonik, bentuk otomatis, dipoles |
| Menyelesaikan |
A: diampelas B: 400#-600# cermin C: garis rambut disikat D: TIN titanlum E : HL brushed & mirror (dua macam finishing untuk satu pipa) |
| Komposisi kimia | |||||||
| Bahan | C | Si | M N | P | S | Cr | Ni |
| 201 | 0.12 | 0.75 | 9.5-12.5 | 0,045 | 0.03 | 13-16 | 0,8-1,5 |
| 304 | 0,08 | 0.75 | 2.0 | 0,045 | 0.03 | 18-19 | 8-10 |
| 316 | 0,08 | 1.00 | 2.0 | 0,035 | 0.03 | 10-14 | 16.0-18.5 |
| 430 | 0.12 | 0.75 | 2.0 | 0,04 | 0.03 | 16-18 | 0.6 |
