6mm Tabung Baja Seamless Cold Rolled Untuk Struktur Otomotif
Properti Dasar
Tempat Asal:
CINA
Nama Merek:
New Era
Sertifikasi:
ISO9001, ISO14001, TS16949
Nomor Model:
ASTM A519, EN 10297-1, JIS G3445
Properti Perdagangan
Jumlah Pesanan Minimum:
1 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
T/T
Kemampuan Pasokan:
2000 Ton/bulan
Ringkasan Produk
Tabung Baja Seamless Untuk Struktur Otomotif Putaran Karbon Mulus Dingin Dingin Presisi Bahan:1010, 1020, 1026,1045, 4130, STKM11A, STKM12B, E235, E255, E355 dll Ukuran: OD: 6mm~168mm WT: 1mm~30mm Panjang: maks 11,8m, atau dipotong Teknik: Draw Dingin / Cold Rolled Permukaan: Minyak Anti Karat ...
Detail Produk
Menyoroti:
Tabung Baja Seamless Cold Rolled 6mm
,Struktur Otomotif Tabung Baja Seamless
,SAE1026 Tabung Baja Dingin Ditarik Seamless
Product Name:
Tabung Baja Karbon
OD Size:
6-168mm
WT Size:
1-30mm
Steel Material:
SAE1020, SAE1026, SAE4130, STKM13A, STKM13B
Application:
Untuk Suku Cadang Mobil, Suku Cadang Mesin
Delivery Time:
45 hari
Deskripsi Produk
Tabung Baja Seamless Untuk Struktur Otomotif
Putaran Karbon Mulus Dingin Dingin Presisi
Bahan:1010, 1020, 1026,1045, 4130, STKM11A, STKM12B, E235, E255, E355 dll
Ukuran: OD: 6mm~168mm WT: 1mm~30mm Panjang: maks 11,8m, atau dipotong
Teknik: Draw Dingin / Cold Rolled
Permukaan: Minyak Anti Karat
Pelindung ujung: Tutup Pipa Plastik
Toleransi: Itu dapat dikontrol dalam OD / Ketebalan +/- 0,1mm
Aplikasi: Suku Cadang Mobil, Suku Cadang Mesin
Tes: Uji Ketegangan, Uji Pembakaran, Uji Flange, Uji Balik, Uji Kekerasan, Uji Listrik Hidrostatis atau Tak Rusak
| Standar | Nilai | Komposisi Kimia (berat%) | ||||||||
| C | Ya | M N | P | S | Cu | Ni | Kr | Mo | ||
| ASTM A519 | SAE 1020 | 0,18-0,23 | / | 0,30-0,60 | ≤0,040 | ≤0,050 | / | / | / | |
| SA 1030 | 0,28-0,34 | 0,60-0,90 | ≤0,040 | ≤0,050 | ||||||
| SAE 1045 | 0,43-0,50 | / | 0,60-0,90 | ≤0,040 | ≤0,050 | / | / | / | / | |
| SA 1524 | 0,19-0,25 | 1.35-1.65 | ≤0,040 | ≤0,050 | ||||||
| SAE 1541 | 0,36-0,44 | / | 1.35-1.65 | ≤0,040 | ≤0,050 | / | / | / | / | |
| SAE 4140 | 0,38-0,43 | 0,15-0,35 | 0,75-1,00 | ≤0,040 | ≤0,040 | 0,80-1,10 | 0,15-0,25 | |||
| EN 10297-1 | E275 | ≤0,21 | ≤0,35 | ≤1.40 | ≤0,030 | ≤0,035 | / | / | / | / |
| E315 | ≤0,21 | ≤0,30 | ≤1,50 | ≤0,030 | ≤0,035 | / | ||||
| E355 | ≤0,22 | ≤0,55 | ≤1,60 | ≤0,030 | ≤0,035 | |||||
| 41Cr4 | 0,38-0,45 | ≤0,40 | 0,60-0,90 | ≤0,035 | ≤0,035 | 0,90-1,20 | ||||
| 34CrMo4 | 0,30-0,37 | ≤0,40 | 0,60-0,90 | ≤0,035 | ≤0,035 | / | 0,15-0,30 | 0,90-1,20 | ||
| 42CrMo4 | 0,38-0,45 | ≤0,40 | 0,60-0,90 | ≤0,035 | ≤0,035 | / | 0,15-0,30 | 0,90-1,20 | ||
| JIS G3445 | STKM13A | ≤0,25 | ≤0,35 | 0,30-0,90 | ≤0,040 | |||||
| STKM13B | ≤0,25 | ≤0,35 | 0,30-0,90 | ≤0,040 | / | |||||
Pertunjukan Produk
