51200 Pipa Tabung Baja Bantalan Kelas Presisi Anil
Properti Dasar
Tempat Asal:
Cina
Nama Merek:
New-Era
Sertifikasi:
ISO9001 ISO14001 TS16949
Nomor Model:
ISO683-17/ASTM A295/A295M
Properti Perdagangan
Jumlah Pesanan Minimum:
5 Ton
Harga:
Dapat dinegosiasikan
Kemampuan Pasokan:
2000 ton Per Bulan
Ringkasan Produk
Bantalan Baja 100Cr6 51200 GCr15 Pipa Baja 1. FiturKekerasan superior, 60-67 pada skala kekerasan Rockwell (Rc) pada suhu kamarBaja paduan krom karbon tinggiBeroperasi terus menerus pada suhu hingga 120 °CDigunakan untuk menghasilkan bantalan bola presisi dan bantalan rolHemat biayaKehidupan kerja ...
Detail Produk
Menyoroti:
51200 tabung baja bantalan
,tabung baja bantalan anil
,51200 tabung mulus canai dingin
Application:
Bantalan
Keyword:
100Cr6,GCr15,52100 bantalan baja
Materials:
100Cr6,GCr15,52100
Surface:
Disesuaikan
Type:
Ditarik Dingin
Size:
OD:10-260mm;WT: 2-30mm;Panjang:1-12000mm
Shape:
Bulat
Product Name:
ISO683-17 Dingin Ditarik Tabung Baja Mulus Bantalan Pipa Baja GCr15 100Cr6
Deskripsi Produk
Bantalan Baja 100Cr6 51200 GCr15 Pipa Baja
1. Fitur
Kekerasan superior, 60-67 pada skala kekerasan Rockwell (Rc) pada suhu kamar
Baja paduan krom karbon tinggi
Beroperasi terus menerus pada suhu hingga 120 °C
Digunakan untuk menghasilkan bantalan bola presisi dan bantalan rol
Hemat biaya
Kehidupan kerja yang panjang
2. Standar Serupa
| Cina | Amerika | Jerman | Jepang |
| GB | AISI | KERIUHAN | JIS |
| GCr15 | SAE52100 | 100Cr6 | SUJ2 |
3. Komposisi Kimia
| Nilai | C | Ya | M N | P | S | Kr | Mo | Cu | Ni |
| GCr15/52100 | 0,95-1,05 | 0,15-0,35 | 0,2-0,4 | ≤0.027 | ≤0,02 | 1.3-1.65 | ≤0,1 | ≤0,25 | ≤0,3 |
| 100Cr6 | 0,95-1,05 | 0,15-0,35 | 0,25-0,45 | ≤0,025 | ≤0,025 | 1.4-1.65 | ≤0,08 | ≤0,25 | ≤0,3 |
4. Perlakuan Panas
| Pendinginan | Tempering | ||||
| Suhu Pemanasan/ºC | Pendinginan | Kekerasan / HRC | Suhu Pemanasan/ºC | Pendinginan | Kekerasan / HRC |
| 830-850 | Minyak | 62-65 | 150-190 | Udara | 58-62 |
5. Sifat Mekanis Baja Bantalan ASTM A295 52100
| Properti | Metrik | Imperial |
| Modulus curah (tipikal untuk baja) | 140 GPa | 20300 ksi |
| Modulus geser (tipikal untuk baja) | 80 GPa | 11600 ksi |
| Modulus elastis | 190-210 GPa | 27557-30458 ksi |
| rasio Poisson | 0,27-0,30 | 0,27-0,30 |
| Kekerasan, Brinell | - | - |
| Kekerasan, Knoop (dikonversi dari kekerasan Rockwell C) | 875 | 875 |
| Kekerasan, Rockwell C (padam dalam minyak dari temper 150°C) | 62 | 62 |
| Kekerasan, Rockwell C (padam dalam air dari suhu 150°C) | 64 | 64 |
| Kekerasan, Rockwell C (padam dalam minyak) | 64 | 64 |
| Kekerasan, Rockwell C (padam dalam air) | 66 | 66 |
| Kekerasan, Vickers (dikonversi dari kekerasan Rockwell C) | 848 | 848 |
| Machinability (anil spheroid dan ditarik dingin. Berdasarkan 100 machinability untuk baja AISI 1212) | 40 | 40 |
Produksi Steel BearingTube 100Cr6/GCr15/52100 :
Tags: Pipa bantalan, 51200, GCr15, 100Cr6, Pipa baja bantalan
