DIN2391 St35 BK Cahaya ditarik keras tabung baja tanpa jahitan
Properti Dasar
Tempat Asal:
Cina
Nama Merek:
New Era
Sertifikasi:
ISO9001,TS16949
Nomor Model:
DIN2391
Properti Perdagangan
Jumlah Pesanan Minimum:
1 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
T/T
Kemampuan Pasokan:
3000 ton/bulan
Ringkasan Produk
DIN2391 St35 BK Cahaya ditarik keras tabung baja tanpa jahitan Bahan: ST35, ST45, ST52 Kisaran ukuran: OD: 6-156mm, WT: 1-30mm, Panjang: 5.8m/6m, maksimum 11.8m Kondisi pengiriman: BK, BKW, BKS, GBK, NBK Aplikasi: Untuk tujuan presisi tinggi, industri otomotif, seperti manipulator, Shock Absorber, ...
Detail Produk
Menyoroti:
Tabung baja tanpa jahitan DIN2391 St35
,tabung baja keras yang ditarik terang
,Tabung Baja Tanpa Jahit yang Tepat
Product Name:
Pipa Baja Presisi
Delivery Condition:
BK,BKW,BKS,GBK,NBK
OD Size:
6-156mm
WT Size:
1-30mm
Standard:
DIN2391 ST52 BK
Application:
tujuan mekanis, tabung struktural
Steel Material:
St35, St45, St52
Delivery Time:
45 hari
Deskripsi Produk
DIN2391 St35 BK Cahaya ditarik keras tabung baja tanpa jahitan
Bahan: ST35, ST45, ST52
Kisaran ukuran: OD: 6-156mm, WT: 1-30mm, Panjang: 5.8m/6m, maksimum 11.8m
Kondisi pengiriman: BK, BKW, BKS, GBK, NBK
Aplikasi: Untuk tujuan presisi tinggi, industri otomotif, seperti manipulator, Shock Absorber, Transmission Shaft, Steering Gear, Car Frame, dll.
Menggambar dingin pada tabung baja tanpa jahitan, untuk mencapai akurasi tinggi pada toleransi OD dan WT
Kondisi pengiriman:
1). BK Dingin selesai (keras)
2) BKW Cold selesai (lembut)
2) BKW Cold selesai (lembut)
3) BKS Cold selesai dan tekanan meringankan
4) GBK Diangkut
5) NBK Normal
5) NBK Normal
100% pengujian arus Eddy.
100% Periksa Toleransi Ukuran.
100% pemeriksaan permukaan tabung untuk menghindari cacat permukaan.
| Nama produk | DIN2391 St35 BK tabung baja karbon tanpa jahitan yang ditarik keras |
| Bahan | ST35, ST45, ST52 |
| Kondisi Pengiriman | BK, BKW, BKS, GBK, NBK |
| Standar | DIN2391 |
| Jangkauan Ukuran | OD: 6-88mm, WT: 1-15mm |
| Aplikasi | Tujuan presisi tinggi, suku cadang mobil, tabung minyak, dll |
| Ronde Billet | Bao Steel, Xingcheng Steel, Huai Steel, Zhongtian Steel |
| Kata Kunci | Tabung baja DIN2391 |
| Sertifikat | TS16949, ISO 9001 |
| Kode HS | 7304319000 |
| Waktu Pengiriman | 45 hari |
| Pengemasan | Paket atau Kotak Kayu |
| Kelas baja | Komposisi Kimia | |||||
| Simbol | Jumlah bahan |
C |
Ya. |
Mn |
P |
S |
| ST35 | 1.0308 | 0.17 | 0.35 | ≥ 0.40 | 0.025 | 0.025 |
| ST45 | 1.0408 | 0.21 | 0.35 | ≥ 0.40 | 0.025 | 0.025 |
| ST52 | 1.0580 | 0.22 | 0.55 | ≤ 1.60 | 0.025 | 0.025 |
| Kelas baja | BK | BKW | BKS | |||||
| Nama | Tidak, tidak. |
Rm |
A |
Rm |
A |
Rm |
ReH |
A |
| ST35 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 315 | 14 |
| ST45 | 1.0408 | 580 | 5 | 520 | 8 | 520 | 375 | 12 |
| ST52 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450 | 10 |
| Kelas baja | GBK | NBK | ||||
| Nama | Tidak, tidak. |
Rm |
A |
Rm |
ReH |
A |
| ST35 | 1.0308 | 315 | 25 | 340--470 | 235 | 25 |
| ST45 | 1.0408 | 390 | 21 | 440-570 | 255 | 21 |
| ST52 | 1.0580 | 450 | 22 | 490-630 | 355 | 22 |
